Position：Home>Product>Computer Case - M-ATX Motherboard Series
|
Model：D32 STD |
| Color：MESH Black |
|
Dimensions (w/o feet and other protrusions)：384mm x 207mm x 302mm (depth/width/height)
|
|
|
|
Case Material：SPCC Steel(0.7mm+0.8mm) |
|
Drive Bay： 2.5": Up to 3 3.5": Up to 1, shared with one of 2.5" mounts
|
|
Front IO Port：USB3.2 Gen1 Type-A*1/USB3.2 Gen 2 Type-C*1/AUDIO*1 & MIC*1 |
|
FAN：Top: 2 x 120mm / 2 x 140mm Rear: 1 x 120mm Bottom: 3 x 120mm / 2 x 140mm |
|
Radiator support：Top，up to 240mm |
|
• When the GPU is installed in the first PCI-E slot of the chassis, the maximum length of the power supply is 150mm, and the recommended length is ≤140mm
• When the GPU is installed in the second PCI-E slot of the chassis, the maximum length of the power supply is 170mm, and the recommended length is ≤160mm
• When the GPU length is ≤288mm, the power supply length is limited to 200mm (not compatible with 16A plugs)
|
|
CPU Air Cooler Clearance：Up to 164mm (Intel CPU) or 163mm (AMD CPU) |
|
GPU Clearance：Up to 365mm |
|
Weight：N.W. 4.1kg / G.W. 5.1kg |
