CR-1000E White

Model：CR-1000E White
Dimensions：120

mm(L)*65mm(W)*154mm(H)

Heatpipe Size：Φ6mm*4 PCS
D-TDP：210W
Fan Dimensions：

120mm* 120mm* 25mm


Fan Speed：600-1500

RPM(±10%)


Fan Air Flow：28.12-59.48 CFM(MAX)
Fan Air Pressure：0.26-1.81 mmH2O(MAX)
Fan Noise Level：22-32 dB(A)(MAX)
Fan Bearing Type：Hydraulic bearings

Fan MTTF： ≥20000h Room Temp：25℃

Connector：PWM 4PIN

Rated Current： LED; FAN: 0.32A
Rated Voltage：LED; FAN: 12V
Power Consumption：LED; Fan: 3.84W
Scope of Application： INTEL: LGA 1700/1200/115X
